- Extraction booth for solvent fumes
Dangerous solvent fumes? Our newly developed ABKAB01 extraction booth
The specification is as demanding as our engineers' solution.
The most important features:
Robust stainless-steel, powder-coated, slim aluminium frame, a large, lockable front flap with gas pressure springs, real glass window, light and with three integrated hand openings for safe work, underneath the two extraction and filtering devices, all fully assembled with easy-running castors - the first impression already instils confidence in this expert work.
The operation confirms the good feeling of safety.
Fatigue-free working as an initial safety aspect because the work place height can be individually adapted. The booth is loaded with work pieces through an additional side flap so that there is no bother with opening the front flap. Solvent fumes created during their processing flow completely into the filtering devices through the rear extractor wall over a large area. Permanently.
Cases of danger? Precautions have been taken.
If solvents are spilled, they are collected by a tray underneath the perforated safety floor. In addition, an explosion-protected gas sensor on the 1st pre-filter measures too high concentrations, e.g. of dichloromethane.
The ABKAB01 extraction booth is fully earthed for continuous potential equalisation in the sense of the EX-protection.
Engineering work which gives you immense added safety, engineering work which distinguishes Fuchs Umwelttechnik and of which we are more than a little proud.
As an established equipper for the laser industry, Fuchs Umwelttechnik presented numerous new products and sophisticated extraction and filtering systems for air purification – developed specially for the widest variety of laser applications. Our company has stood for quality, innovation and sustainable solutions for more than four decades.
Fuchs Umwelttechnik's booth attracted large numbers of visitors for the duration of the fair. Professional visitors took the opportunity for intensive talks with our experts and obtained specific information about our systems – numerous guests to the Automatica also showed great interest in our solutions for mechanical engineering and robotics.
The positive feedback and the high demand endorse Fuchs Umwelttechnik in their claim to be the reference for air purification in laser processes. We would like to thank all our visitors and look forward to new projects and successful cooperation.
The new extraction plate for work benches or lab benches. Inconspicuous and highly efficient.
Solvent or adhesive vapours are escaping during your work at the lab bench which you should not inhale?
Or are you battling with ultra-fine particles which contaminate not only the working environment during your activities?
Whether solder fumes, solvent and adhesive vapours or ultra-fine particles – for the complete extraction of these pollutants, the engineers at Fuchs Umwelttechnik have developed the effective MKFAPL5 extraction plate, especially for installation into work benches or laboratory benches.
Installed flush with the bench surface, the extraction plate collects all emissions. The width of 90 cm ensures sufficient space here for a wide, safe working area. Individual dimensions are possible, of course.
MKFAPL5 – the new bench extraction plate: With professional competence and customer orientation, Fuchs Umwelttechnik once again supplies a sophisticated, useful solution for the protection of man and the environment.
High-quality 1.5 mm sheet steel version
Powder-coated in RAL 7035 ESD
Two NW 50 suction nozzles on rear or bottom
Dimensions L x W x H: approx. 900x100x100 mm
(Other dimensions are available on request)
Fuchs Umwelttechnik is at the LASER WORLD of photonics 2025
The leading international fair "LASER World of PHOTONICS" will be presenting the full range of topics for photonics components, systems and applications in industry and research from the 24th to the 27th of June in Munich.
Fuchs Umwelttechnik will be there again – in Hall B3, Booth 320. Our engineers and technicians will be awaiting you at our new fair booth with individual solutions and sophisticated new development for the safe extraction and filtering of dangerous laser emissions.
A short preview of our new highlights:
- High emission volumes are safety routine for the new system solution INRV pre-separator with rotary airlock as automatic discharge.
- The LSKRS laser protection booth prevents the occurrence of all emissions during laser marking of passing coils and channels the pollutants to the suitable extraction and filtering device via the integrated collection.
- With an interactive demonstration, we present the defined separation for different particle sizes through the new double pre-separator.
Our competent team is looking forward to welcoming you. We will take time to answer your questions and discuss your individual wises on site.
Cash in your ticket voucher for this fair now. See you at our fair booth!
